rám KELLYS THEOS R-series - advanced robotic welded 6-series aluminium alloy / Designed & manufactured in EUROPE / Think Link® suspension system, 130 mm rear travel, integrated removable battery, 1.8" tapered HT, post mount 203 mm, mullet 29 / 27.5+ wheelset, 12x148 mm Boost thru axle
veľkosť rámu S / M / L
motor PANASONIC GX Ultimate, 95 Nm, 36 V
radiaca jednotka PANASONIC
cyklopočítač PANASONIC color LCD side display
batéria KELLYS Re-Charge K1 Li-ion internal removable 725 Wh / capacity 20 Ah, co-developed by Kellys-BMZ
vidlica ROCK SHOX Zeb Select (29) Boost, 150 mm, DebonAir+ / Charger RC / Maxle Stealth 15 mm thru axle
zadný tlmič ROCK SHOX Deluxe Select+ RT, DebonAir+ / Open-Threshold (210x55 mm)
hlav.zloženie ACROS 1.8 tapered semi-integrated
kľuky MIRANDA Delta (34T) - dĺžka 170 mm
radenie SHIMANO Deore XT Linkglide SL-M8130-R Rapidfire Plus (I-Spec EV)
menič SHIMANO Deore XT Linkglide M8130 (direct mount)
počet prevodov 11
kazetový pastorok SHIMANO Linkglide CS-LG600-11 (11-50T)
reťaz SHIMANO Linkglide CS-LG500 (122 článkov)
brzdy SHIMANO SLX M7120 Hydraulic Disc
brzdové kotúče predný SHIMANO RT30 203 mm / zadný EM300 203 mm
brzdové páky SHIMANO SLX BL-M7100
pevná os predná ROCK SHOX Maxle Stealth 15x110 mm / zadná Mr. Control 12x177 mm
zapletané kolesá predné NOVATEC M30 622x30 / zadné NOVATEC M35 584x35 Center Lock (15x110 mm / 2x148 mm)
plášte predný SCHWALBE Magic Mary Evo Super Trail 62-622 (29x2.40) Tubeless Easy, ADDIX Ultra Soft, folding /
zadné SCHWALBE Big Betty Evo Super Trail 65-584 (27.5x2.60) Tubeless Easy, ADDIX Soft, folding
predstavec KLS Alm/En 50 - diam 28.6 mm / bar bore 31.8 mm / dĺžka 60 mm
riadidlá KLS Alm/En 70 RiseBar - diam 31.8 mm / rise 25 mm / šírka 780 mm
rukoväte KLS Poison OneLockon
sedlovka LIMOTEC A1 Remote Telescopic - diam 30.9 mm / dĺžka 445 mm, zdvih 150 mm
sedlo fi´zik Taiga S-alloy rails
pedále plast
